Overview
Type:
Vertical Machining Centers (5-Axis or More)
Manufacturer:
BRETON
Model:
MATRIX 800 K/25
Condition:
New - In-Stock
Year:
2020
Stock #:
1
Status:
For Sale
Description

Breton Mobile Bridge 5-Axis Machining Centre "Matrix 800 K20". Matrix is a “gantry” machining centre with mobile bridge and five interpolated axes to execute high-speed milling operations on metals, light alloys, resins and composite materials. Thanks to its high dynamics and precision, this machine is particularly suitable to perform general machining and to process elements with a complex 3D shape, which call for tight tolerance execution and continuous axis interpolation. Matrix is the perfect solution for modelling, aerospace, automotive and design applications.

Specifications
X78.7"
Y98.4"
Z31.5"
# Axis5
Power50 hp
RPM28,000 RPM
# ATC60
TaperHSK-63A
ControlCNC (Siemens Sinumerik One)
Dimensions177"L x 255.9"W x 197.5"H
Weight48,502 lbs

Supporting Structure - Shoulders - Longitudinal Movement "X" axis travel inch 78.7 "X" axis rapid feed rate ipm 1,969 "X" axis positioning accuracy (P) inch 0.00055 "X" axis positioning repeatability (Ps) inch 0.00039 Floor plate dimensions inch 98.4" / 78.7" "T" slot size inch 0.866 "T" slot pitch inch 7.87" Table payload lb/ft² 1,023
