Overview
Type:
Horizontal Band Saws
Manufacturer:
KARMETAL
Model:
Ultra 300 x 300
Condition:
New - In-Stock
Year:
2021
Stock #:
21457
Status:
For Sale
Description

KARMETAL Model 300 x 300 12' x 12" horizontal bandsaw Servos w/ CNC control Karmetal was founded in 1975 for manufacturing special purpose machines. During 1980’s, Karmetal started to manufacture spare parts for automotive factories and Turkish military. In 1997 we manufactured our first band saw machine. It was additional to spare parts production. In 2002 Karmetal quit spare parts production and focused merely on band saw machines production. We rapidly increased our model quantity and now we are the leading band saw machine manufacturer in Turkey. Quality of Karmetal has been approved with TÜV-SUDVEST DIN EN ISO 9001:2008 and TURQUM quality certificates and our machines are compatible with the CE standards. We provide 2 years warranty for mechanics and 1 year warranty for electric-electronic parts with this convenience Karmetal serves domestic and international market with great reputation and improving its recognition all around the world day by day. We export our machines more than 40 countries including USA,UK, Germany, Australia and Russia. Karmetal has a very strong sales network.

Equipped With

2 year warranty 15" Industrial PC that stores cutting data Intelligent sawing guide software Servo controlled Bow Motion Servo controlled front and rear vises Enclosed cabin for safety Pallet type chip conveyor Hydraulic blade guides High pressure coolant Bevel gear drive for high efficiency LED warning display

Specifications
Rect-Cap (H)11.81"
Rect-Cap (W)11.811"
Rounds-Cap11.81"
Square-Cap11.811"
Power21.6 hp
Type (Auto, Manual, Semi)Auto
Blade Width1.6"
Blade Thickness0.05"
Blade Length284.25"
ControlCNC
Dimensions70.8" x 13'7.4" x 7' 2.6"
Weight13,200 lbs

Main Motor: 21.6 HP Gearbox Bevel Helical PKD 4390 High Efficiency Hydraulic Motor: 2 HP Coolant Motor: 1.5 HP (High Pressure) Conveyor Motor: 0.5 HP Swarf Brush Motor: 1/5 HP Back Feeding Stroke: 18.9" (Multi Indexing) Front Feeding Stroke: 11.8" (Multi Indexing) Back Servo Feeder Motor: 1 HP, 3000 rpm Front Servo Feeder Motor: 1 HP, 3000 rpm Bow Servo Motor: 1 HP, 3000 rpm Blade Speed: 65-1.312 mfpm Blade Dimensions: 23'8¼" x 1.6" x 18" Gauges Machine Weight: 13,200 lbs Machine Dimensions: 70.8" x 13'7.4" x 7'2.6"

KARMETAL Model 300 x 300 12' x 12" horizontal bandsaw Servos w/ CNC control
