W.F. WELLS Horizontal Twin Column Full Hydraulic Saw Model F-16-3 17" x 20" capacity
Have one to sell?
ConditionNew
1 available
New
W.F. WELLS Horizontal Twin Column Full Hydraulic Saw Model F-16-3 17" x 20" capacity
In 1925 William Franklin Wells founded the Wells Manufacturing Corp. to make meat-cutting bandsaws. In 1928 the company introduced a horizontal metal cutting bandsaw, which would later be claimed to be the world's first such saw.
At some point Mr. Wells sold his interest in the business. The new owners emphasized the Wellsaw brand, which had already been in use; the official company name remained the same. In 1948 Mr. Wells formed another company called W. F. Wells & Sons, which also made metal cutting bandsaws.
In 1985 Wells Manufacturing Corp. got into financial trouble and changed hands. In 1991 the new owners of Wells Manufacturing Corp. purchased the assets of W. F. Wells & Sons, and merged the two companies, with the merged company being named W.F. Wells, Inc. The company is still in business today manufacturing horizontal metal cutting band saws.
OPTIONAL FACTORY INSTALLED ACCESSORIES
Description Order Number Price
Discharge Worktable, 22" W x 48" L with Stock Stop 0053201 $3,225.00
Work Light, Wired In 0052021 $400.00
Blade Break/Stall Switch 0056040 $725.00
Hydraulic Chip Conveyor, Auger Style 0056036 $5,750.00
Hydraulic Holddown, Saw Vise 0056486 $3,450.00
Laser Shadow Line 0052220 $3,225.00
Electric Powered Conveyor 21" X 10' 0056204 $11,450.00
High Speed Drive & Guides (1¼" Blade) 400-3000 SFPM 0050271 $8,350.00
Free Standing Non-Powered Conveyors, 6" Centers
21” X 5’ X 5,000 lbs. Cap. Distributed Weight 0050252 $1,950.00
21” X 10’ X 10,000 lbs. Cap. Distributed Weight 0050251 $3,025.00
Capacity: Rectangular at 90° 17″ High x 20″ Wide,
Round at 90° 17″ Diameter
Weight Capacity: 5,000 lbs
Blade Speed: 60-500 SFPM
Blade Size: 1½” X .050″ X 16′ 8″
Blade Guide: Carbide with Roller Backup
Blade Tension: Hydraulic
Bandwheel Size: 22″
Vise: Full Stroke Hydraulic
Blade Drive: 10 HP, AC Vector Drive
Sawing Force: 0-750 lbs
Coolant Capacity: 15 Gallons
Hydraulic Capacity: 20 Gallons
Hydraulic Drive: 2 HP Motor
Work Height: 35″
Shipping Weight: 3,200 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine Dimensions: 101"L x 50"W x 88"H
