W.F. WELLS Model F-1620A-CNC 16" x 20" Fully Automatic with Shuttle Barfeed, Color Touch Screen
Have one to sell?
ConditionNew
1 available
New
Check out the brand new 2023 W.F. WELLS F-1620-A-CNC Horizontal Band Saw! Engineered with a 16" x 20" automatic shuttle barfeed and color touch screen. Specifications include a rectangular capacity of 16" high by 20" wide, round capacity of 16" diameter, and weight capacity of 5,000 lbs. With a powerful 7.5 hp, 3ph, AC vector drive, it's equipped to handle heavy loads. Blade specifications are 1.25" width, 0.042" thickness, and 15' length, operated with hydraulic tension. A robust machine with high-precision features such as unlimited shuffle indexes and projection accuracy of +/- .002". Also includes a CNC programmable controller, bed and vise wear strips, and other optional accessories. Witness the future of precise and heavy-duty sawing. Come see the difference of W.F. WELLS!
OPTIONAL FACTORY INSTALLED ACCESSORIES
Description Order Number Price
Hydraulic Holddown, Saw & Barfeed Vise 0011698 $5,950.00
Hydraulic Chip Conveyor, Auger Style 0056716 $5,750.00
Discharge Worktable (20" Wide x 48" Long) 0011683 $3,225.00
Work Light, Wired In 0011662 $400.00
High Speed Drive & Guides (1” Blade) 400-3000 SFPM 0051037 $8,350.00
Laser Shadow Line 0052220 $3,225.00
Free Standing Roller Stock Conveyors, 6" Centers
21" X 5' X 5,000 lbs. Cap. Distributed Weight 0050252 $1,950.00
21" X 10' X 10,000 lbs. Cap. Distributed Weight 0050251 $3,025.00
Specifications
Capacity ............................. Rectangular at 90º 16" High X 20" Wide, Round 16" Diameter
Weight Capacity ...................... 5,000 lbs.
Blade Speed .......................... 60-500 SFPM
Blade Size ........................... 1¼" X .042" X 15'
Blade Guide .......................... Roller Guides with Carbide Inserts
Vise ................................. Hydraulic, Full Stroke, 15" High
Bandwheel Size ............................. 20" Order
Blade Tension ...............................Hydraulic Voltage Number
Blade Drive .................................7½ HP, AC Vector Drive 208-60-3 0011650
Sawing Force ......................... 0-750 lbs. 230-60-3 0011651
Coolant Capacity ..................... 15 Gallons 460-60-3 0011652
Hydraulic Capacity .................... 20 Gallons 575-60-3 0011653
Hydraulic Drive ...................... 2 HP Motor
Work Height .......................... 35"
Barfeed Projection ....................0 - 25" CNC Controlled
Shuttle Indexes ...................... Unlimited
Projection Accuracy ....................... +/-.002"
Remnant End ................................ 4"
CNC Programmable Controller with Color Touch Screen
500+ Job Selection
Automatic Kerf Compensation
Blade Break/Stall Switch
Bed and Vise Wear Strips
Shipping Weight ............................ 4,000 lbs.
Electrics .................................. Wired to NFPA 79 Machine Tool Standards
Machine Dimensions ......................... 104" Length X 101" Width x 88" Height
