2011 DOOSAN LYNX 300 Lathe, 10" 3 Jaw Chuck, Tailstock, 25.6" Swing
Have one to sell?
ConditionNew
1 available
New
2011 DOOSAN LYNX 300 Lathe, 10" 3 Jaw Chuck, Tailstock, 25.6" Swing
Mid-sized high speed and high precision turning center in a compact structure
Heavy duty cutting available by 15kw high power spindle motor
Equipped With:
20 HP High Torque Spindle
Tailstock
3 Jaw Chuck
Specifications:
Live Tooling No
Y-Axis No
Sub Spindle No
Swing 25.6"
Machining Length 30.1"
# Axis 2
X Travel 10"
Z Travel 31.1"
Chuck Size 10"
Bar Capacity 3"
Power 20 hp
Max RPM 3,500 RPM
Turning Dia 17.7"
Tailstock Yes
Barfeed No
Control CNC (CNC Fanuc)
Dimensions 118x70x67.5
Weight 8,930 lbs
