2025 W.F. WELLS B 25 2A3 CNC
In 1925 William Franklin Wells founded the Wells Manufacturing Corp. to make meat-cutting bandsaws. In 1928 the company introduced a horizontal metal cutting bandsaw, which would later be claimed to be the world's first such saw.
At some point Mr. Wells sold his interest in the business. The new owners emphasized the Wellsaw brand, which had already been in use; the official company name remained the same. In 1948 Mr. Wells formed another company called W. F. Wells & Sons, which also made metal cutting bandsaws.
In 1985 Wells Manufacturing Corp. got into financial trouble and changed hands. In 1991 the new owners of Wells Manufacturing Corp. purchased the assets of W. F. Wells & Sons, and merged the two companies, with the merged company being named W.F. Wells, Inc. The company is still in business today manufacturing horizontal metal cutting band saws.
Description Order Number Price
Discharge Worktable 40" Wide X 56" Long 0052460 $6,825.00
Hydraulic Chip Conveyor 0050180 $6,725.00
Hydraulic Holddown, Saw Vise (console controlled) 0056064 $9,850.00
Hydraulic Holddown, Barfeed Vise (console controlled) 0050119 $10,950.00 Laser Shadow Line 0056319 $3,225.00
Outboard Vise with Hydraulic Holddown 0056063 $17,950.00
Outboard Vise 0056062 $12,395.00
Non-Powered Conveyor 40" X 5' 0050188 $8,375.00
Non-Powered Conveyor 40" X 10' 0050182 $11,875.00
High Speed Drive & Guides (1¼” Blade) 500-3000 SFPM $9,300.00 Mist Coolant 0010774 $3,225.00
Specifications
Capacity ............................. 25" High X 40" Wide, 25½" Diameter Round
Weight Capacity ................. 14,000 lbs.
Blade Speed ...................... 60-500 SFPM
Blade Size ......................... 1½" X .050" X 26' 6"
Blade Guide ....................... Spring Tensioned Carbide Blocks with Idle Roller Backup
Blade Tension .................... Hydraulic Order
Bandwheel Size ................. 26" Voltage Number
Vise ................................... Hydraulic 208-60-3 0010730
Blade Drive ........................ 10 HP, AC Vector Drive 230-60-3 0010731
Sawing Force ..................... 0-1,000 lbs. 460-60-3 0010732
Coolant Capacity ............... 15 Gallons 575-60-3 0010733
Hydraulic Capacity ............. 20 Gallons
Hydraulic Drive .................. 5 HP Motor
Work Height ....................... 35"
Outfeed Table .................... 12" X 41"
Vise Jaw Height ................. 17”
Barfeed Projection ............. 0 - 36" CNC Controlled
Projection Accuracy ........... +/-.002
Shuttle Indexes .................. Unlimited
Remnant End ..................... 14"
Electrics ............................. Wired to NFPA 79 Machine Tool Standards
Hydraulic Positioned Guide Arm, Powered Blade Brush, Blade Break/Stall Switch
CNC Programmable Controller with Color Touch Screen
500+ Job Selection
Automatic Kerf Compensation
Shipping Weight…………….11,000 Shipping Dimensions…….170” L X 102” W X 105” H
