HEM Model V130HM Vertical Double Miter Bandsaw. Can be seen under power in IL. 20" x 24" capacity, 45 degrees L & R

$31,500

Description

HEM Model V130HM Vertical Double Miter Bandsaw Can be seen under power in IL. 20" x 24" capacity, 45 degrees L & R These HEM Vertical Band Saws are time proven band saw designs for cutting materials up to 45 degrees, both left and right. Capacities for these vertical band saw work horses range from (18-25″) wide to (20-36″) high. HEM band saws are well known for their reliability and accuracy. A HEM Vertical Band Saw will give years of accurate band sawing life A. Motor & gearbox are encased in the upper head of the saw away from the coolant and chip area. This engineering philosophy sets us apart from our competitors as, as the life of these components are significantly increased by this protection. B. HEM vertical band saws use only the highest quality standard components such as Lincoln Electric variable speed motors, Borg Warner Morse gearboxes and Allen Bradley electrics. C.

Specifications

ManufacturerHEM
ModelV130HM
Year2000
ConditionUsed
Stock Number21494
CountryUnited States
Throat cap24"
Work height20"
Power10 hp
Blade width1.5"
Blade length17.5'
Fpm400
ControlCNC (Manual Swing Away)
Year new2000
Capacity20" X 24"
Capacity mitter left20" X 16"
Capacity miter right20" X 15"
Capacity (rounds)18"
Blade speeds (variable)72 TO 400 FPM
Blade size1 1/2" X 19'
Guide armHYDRAULIC
Hydraulic vise pressure0 TO 1500 LBS
Hydraucic blade tensionYES
Head tiltsHYDRAULIC
Digital readout displaysYES
CoolantYES
Motor10 HORSEPOWER
