HEM Model V130HM Vertical Double Miter Bandsaw. Can be seen under power in IL. 20" x 24" capacity, 45 degrees L & R
$31,500
Description
HEM Model V130HM Vertical Double Miter Bandsaw Can be seen under power in IL. 20" x 24" capacity, 45 degrees L & R
These HEM Vertical Band Saws are time proven band saw designs for cutting materials up to 45 degrees, both left and right. Capacities for these vertical band saw work horses range from (18-25″) wide to (20-36″) high.
HEM band saws are well known for their reliability and accuracy. A HEM Vertical Band Saw will give years of accurate band sawing life
A. Motor & gearbox are encased in the upper head of the saw away from the coolant and chip area. This engineering philosophy sets us apart from our competitors as, as the life of these components are significantly increased by this protection.
B. HEM vertical band saws use only the highest quality standard components such as Lincoln Electric variable speed motors, Borg Warner Morse gearboxes and Allen Bradley electrics.
C.
Specifications
| Manufacturer | HEM |
| Model | V130HM |
| Year | 2000 |
| Condition | Used |
| Stock Number | 21494 |
| Country | United States |
| Throat cap | 24" |
| Work height | 20" |
| Power | 10 hp |
| Blade width | 1.5" |
| Blade length | 17.5' |
| Fpm | 400 |
| Control | CNC (Manual Swing Away) |
| Year new | 2000 |
| Capacity | 20" X 24" |
| Capacity mitter left | 20" X 16" |
| Capacity miter right | 20" X 15" |
| Capacity (rounds) | 18" |
| Blade speeds (variable) | 72 TO 400 FPM |
| Blade size | 1 1/2" X 19' |
| Guide arm | HYDRAULIC |
| Hydraulic vise pressure | 0 TO 1500 LBS |
| Hydraucic blade tension | YES |
| Head tilts | HYDRAULIC |
| Digital readout displays | YES |
| Coolant | YES |
| Motor | 10 HORSEPOWER |
