Description
STANDARD EQUIPMENT:
Grinding Wheel
Wheel Balancing Arbor
Wheel Flange
Flange Extractor
Diamond Wheel Dresser
Electromagnetic Chuck
Chuck Controller
NC Parallel Dresser
Leveling Screws & Plates
NC Computer Control
Halogen Light
Coolant System
2040HSR
Grinding Wheel: Center Height: 16” x 2” x 5”
24"
Specifications
| Manufacturer | ACRA |
| Model | 2040HSR |
| Year | 2023 |
| Condition | New |
| Stock Number | 21745 |
| Status | For Sale |
| Country | United States |
| Table-W | 20"; 508 mm |
| Table-L | 41"; 1,041.4 mm |
| Spindle (Horz/Vert) | Horz; Horz |
| Power | 15 hp; 11.2 kW |
| Grinding Wheel Width | 2"; 50.8 mm |
| Grinding Wheel Dia. | 16"; 406.4 mm |
| FEATURES | Series |
| Working Surface | 20” x 40” |
| Table Travel | 26” x 45” |
| Wheel RPM | 1,750 |
| Main Motor | 10 HP |
| Voltage | 230/460V AC ~3 PH |
| Dimensions | 148”x90”x90” |
