2012 FERMAT MODEL WFT 13 HORIZONTAL BORING MILL: Travels X=196.8", Y=137.8", Z=78.7"

$299,500

Description

2012 FERMAT MODEL WFT 13 HORIZONTAL BORING MILL: Travels X=196.8", Y=137.8", Z=78.7" FERMAT began in 1990 and was founded by Jiří Ferenc and Mr. Matys, whose last names were used to form the company name. From the outset, FERMAT has benefited from the solid professional ethics of family and friends to guide its excellence. Through strong growth and strategic acquisitions in the Czech Republic and the United States, FERMAT has become the leading manufacturer of the most powerful and accurate horizontal boring and milling machines and cylindrical grinding machines, providing machine tools for all major markets worldwide. Today, FERMAT has more than 470 employees on three continents, producing more than 100 machines a year. FERMAT's main production and assembly facilities are in Brno, the second largest city of Czechia and Lipnik nad Becvou, to the north-east. As FERMAT continues to expand its machine tool range, this capital expansion will continue. Through spindle coolant Exchange of spindle bearings in 2021 Through spindle coolant Max. spindle speed 3000 rev.min Rotary table 2400x2000 94.5" X 78.7"

Specifications

ManufacturerFERMAT
ModelWFT 13
Year2012
ConditionUsed
Stock Number22184
StatusFor Sale
Spindle Size5.1"; 129.54 mm
X-Horiz Tvl of Table196.8"; 4,998.7 mm
Y-Vert Tvl of Head137.8"; 3,500.1 mm
Power49.6 hp; 37 kW
RPM3,000 RPM; 3,000 RPM
Table-W94.5"; 2,400.3 mm
Table-L78.7"; 1,999 mm
Spindle Tvl.28.7"; 728.98 mm
ControlCNC (Heidenhain TNC 530); CNC (Heidenhain TNC 530)
Dimensions440.9" x 489.7" x 250.0"; 440.9" x 489.7" x 250.0"
Weight127,820 lbs; 127,820 lbs
Machine dismantling and LKW loading15 800 Euro
Machine installation, geometry setting26 200 Euro + travel costs
X5000 196.8"
Y3500 137.8"
Z2000 78.7"
W730 28.7"
Max. payload20 000 kg 44,000 LBS.
