DOALL BANDSAW MODEL DC-280NC Cap. 11.75"H X 11"H, 11" Rounds

DOALL BANDSAW MODEL DC-280NC Cap. 11.75"H X 11"H, 11" Rounds The DoALL DC-280NC Continental Series™ high production, horizontal band saw by DoALL is designed for cutting a wide range of metals. The DC-280NC offers fully-automatic operation via a PLC digital control panel and features a solid, heavy-duty construction. The DC-280NC is a tried-and-true favorite for our customers working in high production applications such as aerospace, automotive, primary metal centers and parts production plants. It is both affordable and robust – making it the leading choice for production houses looking to maximize ROI. Standard Equipment • Programmable Logic Controller for all machine functions. • Flushing hose for machine wash down and auxiliary • Feed rate/feed force saw head control. coolant nozzles. • Infinite band speed controlled variable frequency drive. • Hydraulic band tension. • Hydraulic retractable shuttle vice material indexer • Hydraulic adjustable speed auger design chip conveyor. on chrome rails. • Saw band break/stall motion detector shut off switch. • Rapid and creep speed index vice control. • Band door interlocks. • Multi step full stroke cylinder with a split front vice • Operation and parts manuals on USB stick. clamping fore and aft of the sawblade. • One 6.5 ft. (2M) idler input conveyor. • Variable vice pressure control. • Maintenance tool kit. • Vertical hydraulic cylinders with hold down fixtures. • Complimentary DoALL Cutting Fluids package. • Spring loaded, zero clearance, coolant through, • One (1) complimentary DoALL Bi Metal saw blade. carbide faced saw guide inserts with lead in rollers. • Adjustable power driven band cleaning brushes with coolant flush line attached. • Halogen work light. Machine Accessories A. 10 ft Medium-duty idler conveyor 12" between frames. Roller capacity 850 Ibs. 231547 $2,477.00 B. 5 ft Medium-duty idler conveyor 12" between frames. Roller capacity 850 Ibs. 231546 $1,519.00 C. Out of square detection 227746 $3,137.00 D. Additional USB stick of manuals 299998 $95.00 E. Laser line Laser $1,302.00 Saw Blade: Maximum Index Strokes Length 141" Motor HP 5 HP Band Speed 52-430 fpm Floor Space Dimensions: Band Tension Hydraulic W x L X H 83" x 79" x 51" Material Pass Height 27.5" Motor Hp 1 Hp Reservoir Size 16 Gallon Electrical Voltage Requirement 230V-60Hz-3ph, Wye configuration Motor Hp 1/6 Hp Reservoir Size 21 Gallon
