Description
FERMAT WFT 15 CNC Table Type HBM 5.9" spindle; FANUC 31iB. In stock OHIO. Can be equipped with Linear scales & Reinshaw RMP 60 Probe. One of the most popular FERMAT table-type horizontal boring mill, for high-performance machining with maximum utilization of accessories and automatic milling heads for efficient machining of workpieces of up to 20 tons. • Table Size 70.9" x 102.4" • Main Motor 50 HP • Spindle Speed 3,000 RPM • CNC Control FANUC FERMAT
Travel X Axis 157.5" Travel Y-Axis 98.4" Travel Z Axis 59.1" Travel W Axis 31.5"
Spindle Diameter 5.9"
Max. Table Load | lb 44,092 lbs
Table Size in 78.7" x 102.4"
Most popular FERMAT table-type horizontal boring mill, for high-performance machining with maximum utilization of accessories and automatic milling heads for efficient machining of workpieces of up to 20 tons | 44093 lbs. • Spindle diameter 130 mm | 5.1 in or 110 mm | 4.3 in; spindle travel 800 mm | 31.5 in. • Powerful and precise milling, coordinate drilling, boring, and threading. • Extremely versatile series of table-type horizontal boring mills, fully compatible with a wide range of accessories and automatic milling heads. * A large number of accessories are available.
Specifications
| Manufacturer | FERMAT |
| Model | WFT 15 |
| Year | 2025 |
| Condition | New |
| Stock Number | 22300 |
| Status | For Sale |
| Country | United States |
| Spindle Size | 5.9" |
| X-Horiz Tvl of Table | 157.5" |
| Y-Vert Tvl of Head | 98.4" |
| Power | 50 hp |
| RPM | 3,000 RPM |
| Table-W | 70.9" |
| Table-L | 102.4" |
| Spindle Tvl. | 31.5" |
| Control | CNC (FANUC 31iB) |
| Dimensions | 354.3"L x 377.9"W x 210.6"H; 354.3"L x 377.9"W x 210.6"H |
| Weight | 107,000 lbs |
| Automatic Tool Changer | xx Tools |
| Coolant Through Spindle | xx bar High Pressure Unit |
| Outside Coolant System | x bar low pressure |
