2012 MECO MEC-150 CNC Keyseater with CNC Touch Screen, 47.24" Stroke, 59.05" Max Diameter

2012 MECO MEC-150 CNC Keyseater with CNC Touch Screen, 47.24" Stroke, 59.05" Max Diameter MECO MEC ARC-150 x 1150 x 1075 Bridge-Type Vertical Slotter with 43"" Maximum Part Diameter The first bridge-type keyseating machine, ideal for large parts. With a maximum height of up to 45.28" and keyways of between 2.0" and 10.24"wide, this is a machine designed to work with large caliber parts. In addition, the CNC control can control both the cutting speed and feed and the worktop displacement thereby providing greater accuracy and speed. MEC ARC carries out straight, conical, blind hole, internal and external splines and spiral keyseating both inside and outside. In addition, our bridge broaching machine has a powerful motor with electrical safety equipment, plus the automatic system for bringing in the tool to the point where the process starts, allowing adjustment of the path and the separation between cutting edge and part, making it possible to perform fine work even on large parts. Advantages of MEC ARC has a table for handling parts up to 43" in diameter. It is a perfect tool for working in any type of material, even materials that are particularly difficult to machine due to their hardness. It also includes either a Siemens or Mitsubishi CNC with a touch screen that makes it easier to adjust and control the process. Like the other MECO keyseating machines, the MEC ARC has a automatic tool separation system that offers a perfect finish to parts and increases the machine's lifespan. EQUIPPED WITH: MECO CNC touch screen control Servo driven cutting mechanism Automatic indexing table Capable of: – Straight & Conical Keyways – Internal slots – External slots – Multiple slots – Gears Enclosure Ability to do blind parts 3 sets of ball screws Chip collection by worm drive auger PN Type toolholder that allows entire spindle to enter the part Touch screen Table has 6 radial T-slots Spindle alignment system Spindle of 6" diameter for toolholders Cutter centering using two cutters edges to center the cutter Straight slots, Helical Slots, Hexagonal, External Splines, Conical Keyways, Keyways in Blind Samples, Squares, Internal Splines an Blind Holes High Load Working System lets 5-80mm width cutter can cut up to 350 slot Specifications Keyway Capacity: Work Table – Indexing: Workpiece Capacity: 47.24" STROKE, 59.05" MAX. DIA. DIAMETER TABLE, APPROX. 55" DIA. X 43"H MAX. WORKPIECE SIZE, APPROX. 5,500 LB. MAX. WORKPIECE WEIGHT, COOLANT Keyway Width 0" Keyway Length 45.28" Control CNC (Mitsubishi or Siemens) Dimensions 98" W x 157"L x 157"H Weight TBD lbs Description MEC-ARC 150X1150X1075 Premium CNC General dimensions (length, width, height). 157"L x 98.43W x 157"H Machine weight (Aprox). Machine Type Bridge with unique arc Cementing and implantation. No Table dimensions. Ø47.24" Diameter Maximum diameter over the table. (W Axis). Ø42.32" Type of clamping system for the tools: Combined depending on the hole Ø of the piece Clamping for SV tool-holders (holes form Ø2" to Ø10.23"). Morse cone type Clamping for PN tool-holder (holes from Ø9.84"to 42.32", and for external slots):Screws and ring system Extension system for the spindle. Optional Refrigerant system: Yes (15Lts/min) Refrigerant recommended. WD-40 Maximum viscosity of work. From 5 to 10cS at 40ºC (1) Oil filter system. Yes Machine light Yes (800 Lumens) Profitable stroke in “X Axis”. 17.72" CNC model integrated in the machine: SIEMENS or MITSUBISHI (customer's choice, but price is different depending on choice) The parameters below are for SIEMENS Interpolation tolerance at F10000mm/min 0.05mm:
