Specifications
| Manufacturer | Livamak |
| Model | RET100B |
| Year | 2025 |
| Condition | New |
| Stock Number | 22250 |
| Workspindle diameter | 100 mm |
| Clamping taper | 50 ISO |
| Spindle speed range | 10 – 3000 rpm |
| Table transversal travel (X) | 1600 mm |
| Headstock travel (Y) | 1220 mm |
| Table longitudinal travel (Z) | 900 / 1710 mm |
| Spindle stroke (W) | 710 mm |
| Table clamping surface | 1250 x 1250 mm x mm |
| Table loading capacity | max. 3000 kg |
| Tool shank | 69871 RELIGION |
| Clamping adapter – screw | 4100793 TOS |
| Main motor power (S1/S6-40%) | 22 / 34 kW |
| Maximum torque of the spindle (S1/S6-40%) – two speed range | 1097 / 1645 Nm |
| Maximum torque of the spindle (S1/S6-40%) – four speed range | 2173 / 3250 Nm |
| X…transversal travel of table | 1600 mm |
| Z…longitudinal travel of table | 900 / 1710 mm |
| Y…vertical travel of headstock | 1220 mm |
| W…spindle stroke | 710 mm |
| Width of T-slots | 22 H8 mm |
| Table loading capacity – 1250 x 1250 | 3000 kg |
| Table loading capacity – 1500 x 1500 | 2500 kg |
| Feeds… | 4 – 15000 mm / min |
| Feeds… W – automatic mode | 4 – 6800 mm / min |
| Rapid traverse…X, Y, Z | 15,000 mm / min |
| Rapid traverse…W | 6800 mm / min |
| Rapid traverse of table rotation…B | 1.6 rpm |
| Total power consumption | 70 kVA |
| Machine weight | 13000 kg |
| Machine and accessories standard color | white 9010 / green 6018 RAL |
| Fence standard color | black 9011 / yellow 1018 RAL |
| Total area including CE – approximate | 7000 x 5500 mm x mm |
