| Manufacturer | Livamak |
| Model | W100A |
| Year | 2025 |
| Condition | New |
| Stock Number | 22249 |
| Workspindle diameter | 100 mm |
| Clamping taper | 50 ISO |
| Spindle speed range | 1120 rpm |
| Table transversal travel (X) | 1600 mm |
| Headstock travel (Y) | 1120 mm |
| Table longitudinal travel (Z) | 810 / 1250 / 1750 mm |
| Spindle stroke (W) | 900 mm |
| Table clamping surface | 1250 x 1250 mm x mm |
| Table loading capacity | max. 3000 kg |
| Spindle speed range – 23 gears | 7.1 – 1120 rpm |
| Main engine power | 11 kW |
| Main engine speed | 1460 rpm |
| Maximum torque of the spindle – Nmin | 3350 Nm |
| Maximum torque of the spindle – Nmax | 78.5 Nm |
| X…transversal travel of table | 1600 (1800 **) mm |
| Z…longitudinal travel of table – short bed (without steady rest) | 810 mm |
| Z…longitudinal travel of table – long bed (with / without steady rest) | 1750 mm |
| Y…vertical travel of headstock – table 1250 x 1250 | 1120 mm |
| Y…vertical travel of headstock – table 1500 x 1500 | 1100 mm |
| W…spindle stroke | 900 mm |
| Width of T-slots | 22 H8 * mm |
| Table loading capacity – 1250 x 1250 | 3000 (5000 **) kg |
| Table loading capacity – 1500 x 1500 | 2500 (4500 **) kg |
| Centering hole diameter / depth | 280H6 / 8 mm |
| Feeds…X, Y, Z, W, U – 18 gears | 18 – 900 mm / min |
| Feeds…X, Y, Z, W, U – 32 gears | 0.02 – 12 mm / rev |
| Thread feeds…X, Y, Z, W, U – metric – 18 gears | 0.25 – 12 mm / rev |
| Thread feeds…X, Y, Z, W, U – inch – 18 gears | 120 – 2.5 “threads / 1″”” |
| Rapid traverse…X, Y, Z, W, U | 2800 mm / min |
| Rapid traverse of table rotation…B | 1 rpm |
| Total power consumption | 15 kVA |
| Machine and accessories standard color | white 9010 / green 6018 RAL |
| Fence standard color | black 9011 / yellow 1018 RAL |
| Machine weight | 14000 kg |
| Total area including CE – approximate | 5000 x 7500 mm x mm |
| Facing head diameter | 600 mm |
| U…tool slide travel | 210 mm |
| Maximal facing diameter | 900 mm |
| Facing head speed range – 16 gears | 7.1 – 224 rpm |
| Tool shank | Standard Adapter |
| Long shank – metric | DIN 2080 4100744 |
| Long shank – inch | NMTB 50 4100988 |
| Short shank – metric | MAS BT 403-1982 4100793 |
| Short shank – inch | CAT ANSI / ASME B5.50-1985 4100917 |
