NC. 40ZB-2000 CNC Busbar Bending Machine

High-performance CNC busbar bending machine for copper & aluminum. NC. 40ZB-2000 ensures efficient, accurate, and automated busbar fabrication. I. Introduction: The NC.40ZB-2000 CNC busbar bending machine is an efficient, highly automated, and high-precision equipment used for bending copper and aluminum busbars. The machine is powered by servo motors, controlled by CNC units, and equipped with a self-developed CAD/CAM software system. This ensures that the machine's level of automation is at the forefront of the industry. It is an ideal equipment for busbar processing in industries such as complete sets of high and low voltage equipment, box-type substations, transformers, and busbar slots. The machine adopts large inertia servo motor as the main power to provide transmission power for high-precision planetary reducer and grinding ball screw. Compared with the traditional hydraulic bending machine, it has the following advantages: 1.The transmission is stable, the repeated positioning precision is high, the precision is not influenced by the temperature, and the stability is higher. 2.Automatic stop function is available in standby mode, which greatly reduces working energy consumption. 3.The machine adopts servo motor as power, solving the trouble of oil leakage caused by hydraulic transmission. 4.When working, the sound of the servo motor is low, reducing the noise pollution. 5.It has the centering capacity carrying mode, and the linear guide, which balance the stress, and reduce the influence of eccentric load and friction on the service life and processing precision of the lead screw. 6.The material stopping ruler is divided into three gears, which can be adjusted manually according to the processing technology, thereby greatly improving the working efficiency. II. Selection of main accessories: 1 Servo motor Rexroth 1 pc. 2 Spindle lead screw Nanjing Technological Equipment 1 pc. 3 Precision planetary speed reducer TECHMECH 1 pc. 4 Linear guide HIWIN/PEK 5 pcs 5 AC contactor Siemens, Germany 1 pc. 6 Computer Beijing Qiyang 1 pc. 7 Positioning lead screw TBI, Taiwan 1 pc. 8 Industrial switch TP-LINK 1 pc. 9 Programmable controller Beckhoff, Germany 1 pc. Blank here III. Parameter comparison: 1 Nominal pressure KN 400 2 Spindle motor power KW 7.5 3 Bending accuracy ° ±0.3 4 Spindle stroke mm 200 5 Material blocking accuracy mm ±0.15 6 Maximum size of flat bending mm 15×200 7 Maximum size of vertical bending mm 12×120 8 Material blocking length mm 2000 9 Machine weight KG 3300 10 Appearance and size mm 4300×1450×1850 IV. Accessories: 1 Flat bending core R5 1 pc. 2 Flat bending core R10 1 pc. 3 Flat bending cavity 50mm 1 pc. 4 Flat bending cavity 80mm 1 pc. 5 Vertical bending core R30 1 pc. 6 Vertical bending core R100 1 pc. 7 Vertical bending inserting shaft 4 pcs. 8 Accompanying tools 1 set Blank below V. Quality Service: 1.The warranty period is one year. In case of any quality problem within the warranty period, the on-site service shall be provided unconditionally within 24 hours. 2.All mold parts are guaranteed for three months. In case of quality problems within three months, they shall be returned or replaced unconditionally. 3.We provide free delivery, and free debugging training until the mastering of the machine.
